CNC processing type: rust removal, sand blasting, carbonitriding, bushing, turning, milling
Materials: aluminum, stainless steel, bronze, brass, copper, precious metals, steel alloys, precious metals
Micro machining or not: micro machining
Method: CNC milling parts/CNC turning parts
Surface treatment: polishing, etching, vibration grinding, laser engraving
Tolerance:+-0.001 mm
Weight: 0.1~2.0 kg '
Surface treatment: powder coating, nickel plating, zinc plating, chromium plating
Color: OEM
Size: OEM
Our service: OEM and ODM CNC processing according to customer requirements
Equipment: CNC machining center, CNC lathe, CNC turning, milling
Product category: display accessories
Equipment: 3/4/5 axis machine tool, CNC lathe, CNC turning, CNC milling
Certificate: ISO 9001:2015 and IATF 16949
Inspection methods for precision parts processing:
When machining precision parts, roundness measurement method, two-point method and three-point method can be used for detection. The roundness method is to place the measured part on the worktable of the roundness meter, find the rotation center line, and make the probe of the roundness meter contact with the inner hole of the workpiece and rotate. Based on the sensor, amplifier, filter and measuring power circuit, accurate measurement results are finally displayed. If a specific contour map is output, the inscribed circle template can be used to take the radius difference between two tolerance circles on the same ship as the roundness error of a section. This instrument is applicable to parts with high requirements for measurement accuracy.
Precision parts processing:
If the measured profile is an odd edge circle during precision part processing, roundness error cannot be measured by two-point method, but can be measured accurately by three-point method. Support the workpiece to be measured with a V-shaped bracket, and measure the large error caused by one cycle of product workpiece rotation with a micrometer as the roundness error of the section. Common V-shaped intersection angle α 60 degrees, 72 degrees, 90 degrees, 108 degrees and 120 degrees respectively. The three-point method can also be used for high-precision measurement in precision parts processing.
FAQ:
1. How big is your facility?
Our factory covers an area of 3000-5000 square meters, with more than 30 experienced employees, located in Shenzhen, China.
2. How soon can I get the samples?
Depending on your specific project, it usually takes 10 to 20 days.
3. How to enjoy OEM services?
Generally, according to your design drawings or original samples, we will provide you with some technical solutions and quotations. After you agree, we will produce for you.
4. When I send you drawings, what should I clearly indicate?
Please tell us at least the raw materials, finishes and quantities.
7SSwords, can you make design drawings for me?
We do not provide design services. You are responsible for submitting 2D and 3D CAD drawings, and then we can provide manufacturing design review after receiving your order.
